If double-downcountry was a thing, this would be the bike.
Well it is a thing, so embrace it, you’re going to love it. The Ariel 30 rallies up, down and everywhere in between.
From the local loam, to trail centres and natural stuff that a bike with this little travel should have no right being interested in, this is the one that can do it all.
At the heart of it is our all-new, custom-butted and hydroformed 6013 aluminium frame.
Designed and developed with the help of Matt Walker from our Madison Saracen Factory Racing Team, you know it’s been put through the wringer and is built to last and go fast.
Every Ariel 30 features size specific wheels, with small and medium bikes in the 29/27.5 mullet setup, and the large and extra-large sizes 29er models.
But what if you change your mind faster than the bike industry about which wheel size is best?
We thought of that already. Whichever Ariel 30 you choose, we’ve included additional push links that you can swap out and see if the grass really is greener. All you’ll need is the right size rear wheel.
Our Pro model is our top-of-the-line, cutting weight and adding performance across every key component to deliver the best possible performance out on the trails.
The 130mm of travel is provided by a Fox Float X Performance air shock featuring two-position settings, with the matching 34 fork giving low and high-speed compression and rebound adjustment.
Shimano’s latest SLX shifting gives a huge 10-51 range for winching up the steepest slopes, each gear crisply accessed with an XT rear mech. Stopping is handled by Magura MTS four-piston brakes, matched to 180mm rotors for added control.
DT Swiss XM421 rims feature a 25mm internal width and are laced to smooth-spinning Shimano SLX hubs. Maxxis Minion DHRII tyres are spec’d as standard and, along with the rims, are tubeless ready – just add tape, valves and sealant.
Finishing kit is taken care of by RaceFace, with an up-to-date 35mm diameter bar and stem, with the KS Rage dropper completing the package.
When it comes to the details, there is internal routing for everything – including a dropper post – room for a 550ml bottle, superboost spacing for additional clearance, and big bearings which last longer and are commonly available should you need to refresh them.
Please note – this bike does not come supplied with pedals. Choose some here!
Embrace the thrill of double-down country riding with the Ariel 30, a bike that defies expectations and conquers every type of terrain with finesse. From navigating local loam to tackling technical trails that challenge its modest travel, this bike epitomizes versatility and performance. If double-down country was a thing, the Ariel 30 would be the undisputed champion, delivering an exhilarating ride experience that exceeds all expectations.
With size-specific wheels and included push links, the Ariel 30 offers riders the freedom to customize their ride experience like never before. Whether you prefer the agility of a 27.5-inch rear wheel paired with a 29-inch front wheel or the uniformity of a 29er setup, this bike adapts to your preferences effortlessly. Say goodbye to compromise and hello to a ride experience tailored to your exact specifications.
The Ariel 30 Pro model represents the pinnacle of trail bike performance, boasting a lineup of top-of-the-line components meticulously selected to deliver an unparalleled riding experience. With a Fox Float X Performance air shock providing 130mm of travel and a Fox 34 fork offering precise low and high-speed compression and rebound adjustment, this bike is built to handle the most demanding trails with ease. Shimano's latest SLX shifting ensures seamless gear transitions across a wide 10-51 range, while Magura MTS four-piston brakes deliver unmatched stopping power and control. DT Swiss XM421 rims, Maxxis Minion DHRII tires, and RaceFace finishing kit complete the package, ensuring every component is optimized for performance and durability. If double-down country was a thing, the Ariel 30 Pro would set the standard for excellence, leaving riders craving more adrenaline-fueled adventures.
| Frame Size | SMALL | MEDIUM | LARGE | X-LARGE |
|---|---|---|---|---|
| Stem Length plus Reach | ||||
| Frame Seat Tube | 410 cm | 410 cm | 460 cm | 510 cm |
| Frame Top Tube | 625 cm | 625 cm | 653 cm | 682 cm |
| Frame Reach | 480 cm | 480 cm | 505 cm | 530 cm |
| Frame Stack | 604 cm | 604 cm | 618 cm | 632 cm |
| Frame Head Tube | 110 cm | 110 cm | 125 cm | 140 cm |
| Frame Head Angle | 65° | 65° | 65° | 65° |
| Frame Seat Angle | 76.5° | 76.5° | 76.5° | 76.5° |
| Frame Chainstay | 440 cm | 440 cm | 440 cm | 440 cm |
| Frame BB Drop | 30 cm | 30 cm | 30 cm | 30 cm |
| Frame Wheel Base | 1239 cm | 1239 cm | 1270 cm | 1302 cm |
| Fork Offset | ||||
| Fork Travel | ||||
| Standover | 732 cm | 732 cm | 731 cm | 731 cm |
| Stem Length | ||||
| Handle Bar Width |
| Frame Size | SMALL | MEDIUM | LARGE | X-LARGE |
|---|---|---|---|---|
| Stem Length plus Reach | ||||
| Frame Seat Tube | 410 | 410 | 460 | 510 |
| Frame Top Tube | 625 | 625 | 653 | 682 |
| Frame Reach | 480 | 480 | 505 | 530 |
| Frame Stack | 604 | 604 | 618 | 632 |
| Frame Head Tube | 110 | 110 | 125 | 140 |
| Frame Head Angle | 65° | 65° | 65° | 65° |
| Frame Seat Angle | 76.5° | 76.5° | 76.5° | 76.5° |
| Frame Chainstay | 440 | 440 | 440 | 440 |
| Frame BB Drop | 30 | 30 | 30 | 30 |
| Frame Wheel Base | 1239 | 1239 | 1270 | 1302 |
| Fork Offset | ||||
| Fork Travel | ||||
| Standover | 732 | 732 | 731 | 731 |
| Stem Length | ||||
| Handle Bar Width |
