If double-downcountry was a thing, this would be the bike.
Well, it is a thing — so embrace it. You’re going to love it. The Ariel 30 rallies up, down and everywhere in between.
From local loam to trail centres and natural terrain that a bike with this little travel should have no right tackling, this is the bike that can do it all.
At the heart of it is our all-new custom-butted and hydroformed 6013 aluminium frame.
Designed and developed with the help of Matt Walker from the Madison Saracen Factory Racing Team, you know it’s been pushed through the wringer and built to last while going fast.
Every Ariel 30 features size-specific wheels, with small and medium bikes running a 29/27.5 mullet setup, while large and extra-large sizes use full 29er wheels.
But what if you change your mind faster than the bike industry decides on the best wheel size?
We thought of that too. Whichever Ariel 30 you choose, we’ve included additional push links so you can swap them out and experiment. All you’ll need is the correct size rear wheel.
Our Pro model sits at the top of the range, shaving weight and adding performance-focused upgrades across every key component to deliver the best possible ride out on the trails.
The 130mm of travel comes from a Fox Float X Performance air shock with two-position adjustment, while the matching Fox 34 fork offers low- and high-speed compression along with rebound adjustment for precise setup tuning.
Shimano’s latest SLX drivetrain delivers a huge 10?51 gear range for winching up the steepest climbs, while the XT rear mech ensures crisp and reliable shifting. Stopping power comes from Magura MT5 four-piston brakes paired with 180mm rotors for added control and confidence.
DT Swiss XM421 rims feature a 25mm internal width and are laced to smooth-spinning Shimano SLX hubs. Maxxis Minion DHRII tyres come fitted as standard and, along with the rims, are tubeless ready — just add tape, valves and sealant.
RaceFace finishing kit keeps things modern with a 35mm diameter bar and stem, while the KS Rage dropper post completes the package.
When it comes to the details, there’s internal routing for everything — including the dropper post — room for a 550ml bottle, superboost spacing for additional clearance, and large bearings for long-lasting durability and easy servicing.
Please note - this bike does not come supplied with pedals. Choose some here!
Shortlisted for Bike of the Year
A great bike for all-day adventures and picking your way down steep tech. If you like ‘long’ geometry, you’ll love the Ariel 30; pedalling efficiency and snappiness is great between corners; well-thought-out kit provides great value for money. - BikeRadar
| Frame Size | SMALL | MEDIUM | LARGE | X-LARGE |
|---|---|---|---|---|
| Stem Length plus Reach | ||||
| Frame Seat Tube | 360 cm | 410 cm | 460 cm | 510 cm |
| Frame Top Tube | 598 cm | 625 cm | 653 cm | 682 cm |
| Frame Reach | 455 cm | 480 cm | 505 cm | 530 cm |
| Frame Stack | 595 cm | 604 cm | 618 cm | 632 cm |
| Frame Head Tube | 100 cm | 110 cm | 125 cm | 140 cm |
| Frame Head Angle | 65° | 65° | 65° | 65° |
| Frame Seat Angle | 76.5° | 76.5° | 76.5° | 76.5° |
| Frame Chainstay | 440 cm | 440 cm | 440 cm | 440 cm |
| Frame BB Drop | 30 cm | 30 cm | 30 cm | 30 cm |
| Frame Wheel Base | 1210 cm | 1239 cm | 1270 cm | 1302 cm |
| Fork Offset | 44 cm | 44 cm | 44 cm | 44 cm |
| Fork Travel | 130 cm | 130 cm | 130 cm | 130 cm |
| Standover | 732 cm | 732 cm | 731 cm | 731 cm |
| Stem Length | ||||
| Handle Bar Width |
| Frame Size | SMALL | MEDIUM | LARGE | X-LARGE |
|---|---|---|---|---|
| Stem Length plus Reach | ||||
| Frame Seat Tube | 360 | 410 | 460 | 510 |
| Frame Top Tube | 598 | 625 | 653 | 682 |
| Frame Reach | 455 | 480 | 505 | 530 |
| Frame Stack | 595 | 604 | 618 | 632 |
| Frame Head Tube | 100 | 110 | 125 | 140 |
| Frame Head Angle | 65° | 65° | 65° | 65° |
| Frame Seat Angle | 76.5° | 76.5° | 76.5° | 76.5° |
| Frame Chainstay | 440 | 440 | 440 | 440 |
| Frame BB Drop | 30 | 30 | 30 | 30 |
| Frame Wheel Base | 1210 | 1239 | 1270 | 1302 |
| Fork Offset | 44 | 44 | 44 | 44 |
| Fork Travel | 130 | 130 | 130 | 130 |
| Standover | 732 | 732 | 731 | 731 |
| Stem Length | ||||
| Handle Bar Width |
