Saracen Levarg FB
In stock
£999.99
£749.99
More from
Saracen Levarg FB
- Product Details>
- The Brand>
- Specification>
- Sizing & Geometry>
- Delivery & Returns>
- Spare Parts Finder>
- FROM THE CONCRETE JUNGLE TO YOUR LOCAL WOODS, THE LEVARG FLAT BAR BRINGS THE FUN TO WHEREVER YOU RIDE.
- When's a gravel bike a mountain bike? When it has flat 'bars. The Levarg FB is designed to be the ultimate go anywhere ride, taking the city in its stride and with the versatility to hit the trails on the way home.
- We've kept the build simple for minimal fuss and maintenance ‐ a single ring up front and a mid-range cassette is plenty for fast blasts from the door, with the 47c (around 1.9-inch) tyres perfect for mixing parkland, paths, fireroad and singletrack.
- If you want to go a bit further, you'll find the frame is peppered with multiple mounts for bottles, guards and all your bikepacking bits.
- The Series 2 custom butted and hydroformed 6061 alloy frame is matched to a UD carbon fork, with 12mm axles firmly gripping the wheels in place.
- There's a Shimano Deore rear mech working the 11-42 cassette, and hydraulic disc brakes to bring everything back under control.
- The 27.5-inch wheels are matched to 47c Maxxis Rambler tubeless ready tyres, which provide the perfect combination of fast rolling and grip for forestry roads and dusty singletrack.
Versatile Adventure Companion:
Meet the Levarg Flat Bar, your ticket to fun whether you're navigating the concrete jungle or exploring your local woods. Blurring the lines between gravel and mountain biking, this bike is designed to tackle diverse terrain with ease, effortlessly transitioning from urban streets to rugged trails.
Simplicity Meets Performance:
Engineered for minimal fuss and maximum enjoyment, the Levarg FB keeps things simple with a single-ring drivetrain and a mid-range cassette, ideal for quick jaunts straight from your doorstep. Paired with 47c tires, this setup excels on parkland, paths, fire roads, and singletrack, offering versatility for any adventure.
Built for Exploration:
Loaded with multiple mounts for bottles, guards, and bikepacking accessories, the Levarg FB is ready to accompany you on longer journeys and off-grid adventures. Its Series 2 custom butted and hydroformed 6061 alloy frame, along with a UD carbon fork featuring 12mm axles, ensures durability and stability on every ride.
Brake Levers :
Shimano MT-200
Brakes :
Shimano MT-200
Cassette Freewheel :
Shimano CS-M4100 10-Speed 11-42T
Chain :
KMC X10
Chain Set :
Prowheel 42T
Grip Tape :
ODI Elite Motion Lock-On
Handlebars :
Raceface Ride Flat 31.8mm 710mm
Headset :
Prestine PT-1860 ZS44/ZS56
Hubs :
Formula RX812 Front / Formula RX300 Rear
Rear Derailleur :
Shimano Deore RD-M6000 10-Speed
Rims :
Jalco XCD22 32H
Saddle :
Saracen Custom Crmo
Seat Post :
Saracen Alloy 30.9mm
Shifters :
Shimano Deore SL-M6000 10-Speed
Spokes :
Stainless Double Butted
Stem :
Saracen Alloy 31.8mm 70mm
Tyres :
Maxxis Rambler Silkshield 700 x 47mm 60TPI
Wheel Size :
650b
Fork :
12 x 100mm Thru Axle, UD Carbon With Mudguard Eyelets
Fork Material :
Carbon
Frame Material :
Alloy
Brake Type :
Hydraulic Disc
154
156
158
160
162
164
166
168
170
172
174
176
178
180
182
184
186
SMALL
- 154cm to 172cm
MEDIUM
- 170cm to 180cm
LARGE
- 178cm to 186cm
| Frame Size | SMALL | MEDIUM | LARGE |
|---|---|---|---|
| Stem Length plus Reach | 455 cm | 474 cm | 494 cm |
| Frame Seat Tube | 490 cm | 520 cm | 550 cm |
| Frame Top Tube | 560 cm | 585 cm | 610 cm |
| Frame Reach | 385 cm | 404 cm | 424 cm |
| Frame Stack | 572 cm | 590 cm | 609 cm |
| Frame Head Tube | 135 cm | 155 cm | 175 cm |
| Frame Head Angle | 70.5° | 70.5° | 70.5° |
| Frame Seat Angle | 73° | 73° | 73° |
| Frame Chainstay | 425 cm | 425 cm | 425 cm |
| Frame BB Drop | 68 cm | 68 cm | 68 cm |
| Frame Wheel Base | 1044 cm | 1071 cm | 1097 cm |
| Fork Offset | 50 cm | 50 cm | 50 cm |
| Fork Travel | |||
| Standover | |||
| Stem Length | 70 cm | 70 cm | 70 cm |
| Handle Bar Width | 710 cm | 710 cm | 710 cm |
| Frame Size | SMALL | MEDIUM | LARGE |
|---|---|---|---|
| Stem Length plus Reach | 455 | 474 | 494 |
| Frame Seat Tube | 490 | 520 | 550 |
| Frame Top Tube | 560 | 585 | 610 |
| Frame Reach | 385 | 404 | 424 |
| Frame Stack | 572 | 590 | 609 |
| Frame Head Tube | 135 | 155 | 175 |
| Frame Head Angle | 70.5° | 70.5° | 70.5° |
| Frame Seat Angle | 73° | 73° | 73° |
| Frame Chainstay | 425 | 425 | 425 |
| Frame BB Drop | 68 | 68 | 68 |
| Frame Wheel Base | 1044 | 1071 | 1097 |
| Fork Offset | 50 | 50 | 50 |
| Fork Travel | |||
| Standover | |||
| Stem Length | 70 | 70 | 70 |
| Handle Bar Width | 710 | 710 | 710 |
